Intel X710-T2L Dual / 2 Port 10GbE PCI-E X8 Ethernet Kart - StorNET

Intel X710-T2L Dual / 2 Port 10GbE PCI-E X8 Ethernet Kart - StorNET
11.610,00 TL KDV dahil.
Kategori
RJ45 Ethernet kartı | 10 Gigabit , Projeniz için Ürünler
Marka
StorNET
Stok Kodu
X710T2L
Garanti Süresi
24 Ay
Ürün Durumu
Sadece Yeni ve Orjinal Kutulu Ürün satıyoruz.
Fiyat
11.610,00 TL KDV dahil.
Aynı Gün Kargo
Karşılaştır
Ürün Bilgisi
Yorumlar
Teknik Detay

Ethernet Kartı NBASE-T 10GBASE-T intel ChipSet X710-T2L Dual Port

▪ PCI Express (PCIe) v3.0, x8
▪ Energy Efficient Ethernet (EEE) / IEEE 802.3az enabled
▪ Backward compatible with multi-speed support for 5/2.5/1GbE, 10GBASE-T, and 100BASE-TX
▪ Network Virtualization offloads including VxLAN, GENEVE, NVGRE, MPLS, and VxLAN-GPE with Network Service Headers (NSH)
▪ Intel® Ethernet Flow Director for hardware-based application traffic steering
▪ Dynamic Device Personalization (DDP) enables increased packet processing efficiency for NFV and Cloud deployments
▪ Data Plane Development Kit (DPDK) optimized for efficient packet processing
▪ Excellent small packet performance for network appliances and Network Functions  Virtualization (NFV)
▪ I/O virtualization innovations for maximum performance in a virtualized server


Specification
• PCI-Express host interface specification v3.0 with 8GT/s Bus width and backward compliant with 2.0 and 1.x
• PCI-Express interface: x8
• Complies with Dual 10GbE RJ45 port
• Integrate BASE-T ports capable of operating at 100/1G/2.5G/5G/10GBASE-T
• Full-duplex operation at all supported speeds
• Maximize link capacity when operating at 10Gb/s link with packets larger than 128 bytes at full duplex traffic
• PCI-SIG SR-IOV implementation 128 per device
• Supports Receive-side scaling (RSS)
• Supports Jumbo Frames up to 9K
• Supports Tx/Rx IP, SCTP, TCP, and UDP checksum offloading (IPv4, IPv6) capabilities
• Next-generation VMDQ up to 256 maximum VMDQ VMs supported
• Virtual machine load balancing
• Advanced packet filtering
• VLAN support with VLAN tag insertion, stripping and packet filtering for up to 4096 VLAN tags

Intel X710-T2L Dual / 2 Port 10GbE PCI-E X8 Ethernet Kart - StorNET genel Özellikleri

Slot Demirler : Low Profile ( Kısa Demir ), Full Height ( Uzun Demir )
Port Tipi : RJ-45
Transfer Hızı : 10 Gbps / Her Port
Port Sayısı : 2 Port Dual
Marka : StorNET
Bus type : PCIe Gen3x8
ChipSet : intel
PoE tipi : PoE yok
Teknoloji : Ethernet Kart
Bu ürüne ilk yorumu siz yapın!
Yorum Yaz

Essentials

Product Collection

Intel X710T2L 10GbE Network Adapter

Controller Processors

Intel X710-AT2

Bus Type/Bus Width

PCI Express (PCIe) 3.0 x8

Connections

2 x RJ45 Copper

Data Rate Supported

10GbE/5GbE/2.5GbE/1GbE/100Mb



Transmission Media

RJ45 Copper

2.5GBASE-T and 5GBASE-T: 100 m using CAT5e, CAT6, or CAT6A

10GBASE-T: 55 m using CAT6, 100 m using CAT6A

100BASE-TX and 1000BASE-T: 100 m using CAT5e, CAT6, or CAT6A

Bracket

Low Profile and Full Height

Dimension

167 mm x 69 mm (PCIe Board)

Technical Specifications

Interrupt Levels

INTA, MSI, MSI-X

Manageability

PXE, UEFI, SNMP

Virtualization Technology

VMDQ, PCI-SIG, SR-IOV, Virtual machine load balancing advanced packet filtering, VLAN, VxLAN, GENEVE, NVGRE, MPLS, VxLAN -GPE, NSH

System Requirements

Windows Client

Windows 11/ 10

Windows Sever

2008/ 2012/ 2016/ 2019/ 2022

Linux

RHEL7.9/ 8.4/ 8.5, SLES12SP5, SLES15SP3, Ubuntu18.04LTS/ 20.04LTS, FreeBSD 12.2/ 13

Environment & Certification

Power Consumption

Max. 9.6W

Airflow

Dual Port: 100 m: 35 °C to 40 °C,

                 350-400 recommended LFM

Storage Humidity Maximum

90% non-condensing relative humidity at 35 °C

Storage Temperature

-40 °C to 70 °C (-40 °F to 158 °F)

Operating Temperature

0 °C to 55 °C (32 °F to 131 °F)

LED Indicators

LINK (Green = 10Gbps; Yellow = 5/2.5/1Gbps; OFF = 100Mbps)

ACT (Blinking Green = transmitting or receiving data; OFF = no link)

Certifications

CE   FCC   RoHS
